Home >> Chrysler >> 2005 >> Sebring Base, 2D Coupe >> Repair and Diagnosis >> Engine Performance >> Ignition System - Coupe >> Distributor Assembly < 3.0L Engine > >> Removal And Installation >> Notes

Removal And Installation: Notes

Fig 1: Removing/Installing Ignition Coil (3.0L Engine)

G04537480

Courtesy of DAIMLERCHRYSLER CORPORATION
