Liftgate Cylinder Lock Switch: Installation

  1. Install liftgate cylinder lock switch on rear of liftgate lock cylinder without rotating the switch. See Figure.
  2. Install the liftgate cylinder U-bracket by sliding it in.
  3. Install switch E-clip and connector.
  4. Install the liftgate trim panel (Refer to BODY/DECKLID/HATCH/LIFTGATE/TAILGATE/TRIM PANEL - INSTALLATION) .
  5. Connect the battery negative cable. See Figure.
  6. Close hood.
  7. Verify vehicle and system operation.
