Intake Manifold: Installation

WARNING: This page is about a different variant/trim than selected.
Fig 1: Identifying Intake Manifold Components
GC0034723Courtesy of DAIMLERCHRYSLER CORP.
  1. Install the intake plenums and gaskets.
  2. Tighten the plenum hose clamp (1).
    Fig 2: Removing/Installing Intake Plenums
    GC0032355Courtesy of DAIMLERCHRYSLER CORP.
  3. Install the intake plenum retaining bolts (1).
  4. Install the lower air cleaner housing. (Refer to ENGINE/AIR INTAKE SYSTEM/AIR CLEANER HOUSING - INSTALLATION) .
  5. Install the upper air cleaner housing. (Refer to ENGINE/AIR INTAKE SYSTEM/AIR CLEANER HOUSING - INSTALLATION) .
  6. Install the front engine cover. (Refer to ENGINE - INSTALLATION) .
