Engine - Inside Oil Pan Components (LIH)
Engine - Inside Oil Pan Components (LIH)
| Component Name | Callout |
|---|---|
| Q12 Evaporative Emission Purge Solenoid Valve Q12 Evaporative Emission Purge Solenoid Valve | 1 |
| B52A Heated Oxygen Sensor 1 B52A Heated Oxygen Sensor 1 | 2 |
| Q40 Turbocharger Bypass Solenoid Valve Q40 Turbocharger Bypass Solenoid Valve | 3 |
| B52B Heated Oxygen Sensor 2 B52B Heated Oxygen Sensor 2 (LIH) | 4 |
| B23E Camshaft Position Sensor - Exhaust B23E Camshaft Position Sensor - Exhaust | 5 |
| B34 Engine Coolant Temperature Sensor (LIH) B34 Engine Coolant Temperature Sensor | 6 |
