Front Seat Lane Departure Warning Actuator Replacement

Fig 1: Front Seat Lane Departure Warning Actuator
GM3273238Courtesy of GENERAL MOTORS COMPANY
Callout Component Name
WARNING:

Refer to SIR Warning .

Preliminary Procedure

  1. Remove the driver or passenger seat. Refer to Driver or Passenger Seat Removal and Installation .
  2. Remove the front seat cushion cover and pad. Refer to Front Seat Cushion Cover and Pad Replacement .
1 Driver Front Seat Cushion Haptic Motor

Procedure

  1. Reposition the heater element as needed to gain access to the actuator wire.
  2. Disconnect the electrical connector.
