Special Tools

Illustration	Tool Number/Description
Courtesy of GENERAL MOTORS CORP.	CH-48027 Digital Pressure Gage
Courtesy of GENERAL MOTORS CORP.	EN-47909 Injector Bore and Sleeve Cleaning Kit
Courtesy of GENERAL MOTORS CORP.	EN-47969 Fuel Supply Diagnostic Hose
Courtesy of GENERAL MOTORS CORP.	EN-48565 EGR Test Harness
Courtesy of GENERAL MOTORS CORP.	J-25070 Heat Gun 500-750°F
Courtesy of GENERAL MOTORS CORP.	J-28428-E High Intensity Black Light Kit
Courtesy of GENERAL MOTORS CORP.	J-34730-405 Injector Test Lamp
Courtesy of GENERAL MOTORS CORP.	J-35555 Metal MityVac
Courtesy of GENERAL MOTORS CORP.	J-35616-200 Test Light - Probe Kit
Courtesy of GENERAL MOTORS CORP.	J-36169-A Fused Jumper Wire
Courtesy of GENERAL MOTORS CORP.	J-38522 Variable Signal Generator
Courtesy of GENERAL MOTORS CORP.	J-38641-B Diesel Fuel Quality Tester
Courtesy of GENERAL MOTORS CORP.	J-43178 Fuel Line Disconnect Tool
Courtesy of GENERAL MOTORS CORP.	J-43181 Heater Line Q. C. Release Tool
Courtesy of GENERAL MOTORS CORP.	J-43244 Relay Puller Pliers
Courtesy of GENERAL MOTORS CORP.	J-44581 Fuel Line Disconnect Tool
Courtesy of GENERAL MOTORS CORP.	J-45004 Fuel Tank Drain Hose
Courtesy of GENERAL MOTORS CORP.	J-45722 Fuel Sender Lock Ring Wrench
Courtesy of GENERAL MOTORS CORP.	J-45873 Fuel Return Volume Test Kit
Courtesy of GENERAL MOTORS CORP.	J-45873-30 Injector Flow Test Adapter
Courtesy of GENERAL MOTORS CORP.	J-46091 Charge Air Cooler Tester
Courtesy of GENERAL MOTORS CORP.	J-46091-10 Charge Air Cooler Tester Adapter
Courtesy of GENERAL MOTORS CORP.	J-46091-15 Engine Pressure Test Adapter
Courtesy of GENERAL MOTORS CORP.	J-46594 Fuel Injector Puller
