Liftgate Outside Handle Replacement

WARNING: This page is about a different car, the 2011 Chevrolet HHR. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: Liftgate Outside Handle
GM1602212Courtesy of GENERAL MOTORS COMPANY
Liftgate Outside Handle Replacement

Callout Component Name
1 Liftgate Handle Bolts (Qty: 2)
CAUTION:

Refer to Fastener Caution .


Tighten
10 N.m (89 lb in)
2 Liftgate Handle
TIP:  Disconnect electrical connector.
