Installation Procedure

WARNING: This page is about a different car, the 2003 Pontiac Montana, 2003 Oldsmobile Silhouette, and 2003 Chevrolet Venture. However, it is still accessible from the selected car via links, so may be relevant.
  1. Install the air compressor shield.
  2. Install the automatic level control air compressor. Refer to AIR COMPRESSOR REPLACEMENT   .
    Fig 1: Installing Air Compressor Shield
    G01483373Courtesy of GENERAL MOTORS CORP.
