Installation Procedure

NOTE: Use the correct fastener in the correct location. Replacement fasteners must be the correct part number for that application. Fasteners requiring replacement or fasteners requiring the use of thread locking compound or sealant are identified in the service procedure. Do not use paints, lubricants, or corrosion inhibitors on fasteners or fastener joint surfaces unless specified. These coatings affect fastener torque and joint clamping force and may damage the fastener. Use the correct tightening sequence and specifications when installing fasteners in order to avoid damage to parts and systems.
  1. Install the seat belt buckle (1) to the front seat. Secure the buckle with the bolt.

    Tighten

    Tighten the front seat belt buckle bolt to 42 N.m (31 lb ft).

  2. Install the inner adjuster finish cover (2) to the front seat. Secure the cover with the screw.
    Fig 1: Installing Inner Adjuster Finish Cover To Front Seat
    G01639378Courtesy of GENERAL MOTORS CORP.
  3. Connect the seat belt switch electrical connector (2), on the left front buckle only.
  4. Install the front floor rear console. Refer to CONSOLE REPLACEMENT -- REAR FLOOR .
  5. Return the front seat (1) to the upright position, if the left front buckle was removed.
    Fig 2: Returning Front Seat To Upright Position
    G01639379Courtesy of GENERAL MOTORS CORP.
