Fuse Panel Identification
NOTE:
A 15-Amp A/C fuse is located on engine firewall. Cruise control is fitted with a 1-Amp in-line fuse.
- 1 - 10 Amp - Right Side Headlights
- 2 - 10 Amp - Left Side Headlights
- 3 - 15 Amp - Stoplights
- 4 - 15 Amp - Dome Light, High Beam Indicator, Door Warning, Horn
- 5 - 5 Amp - License Light, Instrument Panel Illumination
- 6 - 15 Amp - Right Side Marker & Park Lights
- 7 - 15 Amp - Left Side Marker & Park Lights
- 8 - 20 Amp - Ignition Coil, Distributor, Engine Computer, Radiator Fan, Fuel Gauge, Temperature Gauge, Warning Indicators
- 9 - 20 Amp - Heater Control
- 10 - 20 Amp - Rear Defogger
- 11 - 15 Amp - Front & Rear Wiper/Washer
- 12 - 10 Amp - Turn Signal Flasher, Back-Up Lights
- 13 - 15 Amp - Hazard Flasher
- 14 - 15 Amp - Radio, Cigarette Lighter
