Removal Procedure

WARNING: This page does not describe the selected car, but rather 6 other vehicles, including the 2003 GMC Savana Special, 2003 GMC Savana Camper Special, 2003 GMC Savana, 2003 Chevrolet RV Cutaway, and 2003 Chevrolet Cutaway. However, it is still accessible from the selected car via links, so may be relevant.
  1. Remove the sliding side door upper roller bracket cover. Refer to Roller Bracket Cover Replace - Sliding Door Upper .
  2. Remove the sliding side door upper track garnish molding. Refer to Garnish Molding - Rear Side Door Upper Track .
  3. Remove the sliding side door upper trim panel. Refer to Trim Panel Replacement - Sliding Door .
  4. Remove the passenger side front corner garnish molding. Refer to GARNISH MOLDING REPLACEMENT - RIGHT SIDE FRONT .
  5. Remove the bolts that retain the upper roller bracket to the door.
  6. Remove the sliding side door upper roller bracket from the rear of the upper track.
  7. Remove the sliding side door upper roller bracket from the vehicle.
    8. Fig 1: Removing Sliding Door Upper Roller Bracket
    G02423124Courtesy of GENERAL MOTORS CORP.
