Display and operating concept: Notes
The engine oil level check with the oil level sensor is coupled with a change to the display and operating concept.
Qualitative measurement while driving
- Status display (oil level OK, oil level at or below minimum)
- Display available at all times
- Warning by means of Check Control message from oil level at minimum
| Item | Explanation |
|---|---|
| 1 | Vehicle status |
| 2 | Engine oil level OK |
| 3 | Engine oil level at maximum. Please top up with one litre of engine oil. |
| 4 | Engine oil level below minimum. Please top up immediately with one litre of engine oil. |
