31 00... Front axle + steering work requiring subsequent wheel alignment check
WARNING: This page is about a different car, the 2018 BMW X5, 2017 BMW X5, 2016 BMW X5, 2015 BMW X5, and 2014 BMW X5. However, it is still accessible from the selected car via links, so may be relevant.
A WHEEL ALIGNMENT CHECK must be carried out after the following work:
- Release of following screw/bolt connections:
- Steering gear to front axle support (only if components are not marked for alignment)
- Lower wishbone to front axle carrier
- Track rod end to track rod
- Replacement of following parts:
- Front axle support
- Steering box
- Swivel bearing
- Track rod end
- Lower wishbone / rubber mount
- Track rod
- Gaiter (if the tie rod end has to be screwed off)
