Modifications to "Condition Based Service" maintenance system

Fig 1: Modifications To "Condition Based Service" Maintenance System

Courtesy of BMW OF NORTH AMERICA, INC.

Background:

• Passenger compartment microfilter:  Link to a multiple of the oil service.
• Spark plugs:  Link to a multiple of the oil service.
• Diesel particulate filter:  Critical range covered by Check Control.
• Exhaust emissions test:  Cancellation in all regions except V6 China (can also be controlled manually via DIS Tester).

For precise coupling, please refer to:

• China
• V5
• V1, V3 and V4 Canada
• V4 USA

Date of introduction:

• Displays for interior microfilter, spark plugs and emissions test discontinued (revised encoding).
