61 20 005 Testing battery with battery tester

WARNING: This page does not describe the selected car, but rather 50 other vehicles, including the 2016 BMW M5, 2016 BMW ActiveHybrid 5, 2016 BMW 550i xDrive, 2016 BMW 550i, and 2016 BMW 535i xDrive. However, it is still accessible from the selected car via links, so may be relevant.

IMPORTANT: Check is not permissible for AGM and lithium ion batteries!
Check does not apply to F-series!

WARNING: Observe SAFETY INFORMATION on the 12 V battery.

Necessary preliminary tasks:

Remove luggage compartment floor trim panel.

Procedure:

Turn off ignition and close doors
Connect battery tester directly to battery terminals
Select Battery test and confirm
Enter vehicle identification number
Enter battery data
Carry out battery test

Fig 1: Connecting Battery Tester To Battery Terminals
Courtesy of BMW OF NORTH AMERICA, INC.

Refer to 61 20 005 TESTING BATTERY WITH BATTERY TESTER
