Common Battery Terms

This rating is derived from discharging a fully charged battery at a constant amp draw for 20 hours @ 80°F, without the voltage of the battery falling below 10.5 volts. The constant amp draw is multiplied by the 20 hours to come up with the Amp Hour Rating.

Represents the amperage capacity a fully charged battery can deliver @ 0°F for 30 seconds before the voltage of the battery falls below 7.2 volts.

Reserve capacity is expressed in minutes and relates to the amount of time a fully charged battery can maintain a constant draw of 25 amps @ 80°F before the voltage falls below 10.2 volts.

The measurement of electrical power that the battery can deliver for a cold start. It is calculated by multiplying the starter amperage draw @ 0°F times 10 volts.

Unit of measure of potential difference (Electrical pressure).

The current flow in a circuit. Value is proportional to the number of electrons flowing past a point in one second.

The measurement of the resistance of a component or circuit to current flow.

The mixture of sulfuric acid and water. 35% sulfuric acid, 65% water.

The measurement (by weight) of the volume of sulfuric acid in the electrolyte. A specific gravity of 1.275 (the specific gravity of a fully charged battery) means that the electrolyte is 1.275 times heavier than water. The specific gravity of water is 1.000.

Deposits formed on the plates of the battery as the electrolyte gives up its sulfuric acid. Excessive deep cycling of a battery can cause a hardening of this deposit and make it impossible to return sulfate to the electrolyte. A sulfated battery is one which has these hardened deposits on the plates and cannot be recharged to full capacity.

The measurement of the voltage of a battery across the terminals.
