Chip Card Reader Control Module, Information Electronics Control Module 1, Windshield Projection Head Up Display Control Module, Traffic Data Antenna
J676
Chip Card Reader Control Module
J794
Information Electronics Control Module 1
J898
Windshield Projection Head Up Display Control Module
R173
Traffic Data Antenna
T2eqx
2-Pin Connector, Black
T2jo
2-Pin Connector, Black
T2ka
2-Pin Connector, Black
T8m
8-Pin Connector, Black
T10ac
10-Pin Connector, Black
T12l
12-Pin Connector, Gray
T17k
17-Pin Connector, Red
T17kx
17-Pin Connector, Red
TALU
Coupling Point on Left A-Pillar, Bottom
TARU
Coupling Point on Right A-Pillar, Bottom
*
For Vehicles with Japan Equipment
*2
Pre-Wired Component
*3
Refer to Applicable Windshield Projection Wiring Diagram
*4
Refer to Applicable Wiring Diagram for Infotainment Most Bus
*5
For Vehicles with Cell Phone/Telephone
*6
For Vehicles with Windshield Projection
*7
Depending on Equipment
*8
For Vehicles with a Cell Phone/Telephone Prep
*9
Optional Equipment
*10
For Vehicles with Bose Sound System
