Airbag Control Module, Data Bus On Board Diagnostic Interface, Lane Change Assistance Control Module 2

Courtesy of AUDI

J234

Airbag Control Module

J533

Data Bus on Board Diagnostic Interface

J769

Lane Change Assistance Control Module

J770

Lane Change Assistance Control Module 2

T14y

14-Pin Connector, Black

T14z

14-Pin Connector, Black

T54a

54-Pin Connector, Black

T142b

142-Pin Connector, Yellow

T142c

142-Pin Connector, Yellow

*

Refer to Applicable Lane Change Assistance Wiring Diagram

*2

For USA Only

*3

Not for USA

*4

For Vehicles with Lane Change Assistance
