3.2L - Ignition/Glow Plug System, Engine Code(S): BHE
>>
Ignition/Glow Play System
>>
Ignition system, checking
>>
Ignition coils, removing and installing
>>
Installing
Ignition coils, removing and installing: Installing
Install in reverse order of removal. Note the following:
Insert ignition coils into holes so that flat edges align with one another (arrows).
Fig 1: Inserting Ignition Coils Into Holes
Courtesy of AUDI OF AMERICA, INC.
