Removal And Installation

REMOVAL

1. Raise the seat until to the end of travel position.
2. Disconnect and isolate the negative battery cable.
3. Remove the front seat side shield. Refer to SIDE SHIELDS, SEAT CUSHION, FRONT, REMOVAL AND INSTALLATION .

   Courtesy of CHRYSLER GROUP, LLC

4. Release the memory seat switch retainers (1a) and remove the switch (1b).

INSTALLATION

1. Inspect the memory seat switch integrity.

   Courtesy of CHRYSLER GROUP, LLC

2. Install the memory seat switch (1a) and secure the retainers (1b).
3. Install the front seat side shield. Refer to SIDE SHIELDS, SEAT CUSHION, FRONT, REMOVAL AND INSTALLATION .
4. Connect the negative battery cable.
