With New Retainer

1. Connect the retainer (M) to the connector (N). (Figure 10)

NOTE: Make sure the locking tabs (O) are firmly installed in the connector grooves. (Figure 10)

Figure 10

Courtesy of HONDA, U.S.A., INC.

2. Connect the quick-connect fittings (P) to the fuel line (Q) until a click sound is heard. (Figure 11)

NOTE: Make sure the bulge (R) is firmly installed in the retainer groove. (Figure 11)

Figure 11

Courtesy of HONDA, U.S.A., INC.
