Evaporator Temperature Sensor Replacement

  1. Remove the driver's dashboard undercover (see DRIVER'S DASHBOARD UNDERCOVER REMOVAL/INSTALLATION ).
  2. Disconnect the connectors (A) from the adaptive front lighting control unit, the electronically controlled power steering control unit, and the daytime running lights control unit. Remove the relay (B), the bolt, and the self-tapping screws, then remove the bracket (C).
    Fig 1: Disconnecting Connectors From Adaptive Front Lighting Control Unit With Torque Specifications
    G07354802Courtesy of AMERICAN HONDA MOTOR CO., INC.
  3. Disconnect the connectors (A) from the evaporator temperature sensor and the driver's cool vent control motor, then remove the connector clip (B). Remove the self-tapping screw and the evaporator temperature sensor (C).
    Fig 2: Disconnecting Connectors From Evaporator Temperature Sensor And Driver's Cool Vent Control Motor
    G07354803Courtesy of AMERICAN HONDA MOTOR CO., INC.
  4. Install the sensor in the reverse order of removal.
