Display Panel Control Unit Inputs and Outputs for Connector B (6P)

Fig 1: Identifying Connector B (6P) Display Panel Control Unit Inputs And Outputs

G03662506

Courtesy of AMERICAN HONDA MOTOR CO., INC.
