ECM/PCM Inputs and Outputs at Connector D (17P)-2005-2006 Models

Fig 1: Identifying ECM/PCM Connector D (17P) And Terminal Description

G03650544

Courtesy of AMERICAN HONDA MOTOR CO., INC.
