RECIRCULATION Control Motor

CAUTION: After motor operates, remove power source as soon as possible to prevent motor damage.
  1. Connect battery voltage to terminal No. 1 on recirculation control motor. Connect terminal No. 2 to ground. Using jumper wire, connect terminals No. 1 and 2. With FRESH/RECIRC door in RECIRC position, motor should rotate 1/2 turn and stop. Disconnect jumper wire.
  2. Using jumper wire, connect terminals No. 2 and 4. With FRESH/RECIRC door in FRESH position, motor should rotate 1/2 turn and stop. If motor operation is not as specified, replace recirculation control motor. See Figure .
